Description

Vertical Inline High Pressure Pump – FG2-9 (BSBD)

Motor Single Phase 1.5 H.P/1.1 kw.

The FG2-11 (BSBD) Vertical Inline High Pressure Pump by Flowguards is designed for reverse osmosis (RO) plants and compact water purification systems with a capacity ranging from 500 to 750 liters per hour (LPH). This pump ensures a consistent high pressure, efficient water flow, and reliable performance for continuous operation.

The vertical inline design allows for the pump to be installed directly within the pipeline, thereby reducing installation space and optimizing system layout. Made from high-quality materials and engineered with precision, the FG2-11 pump provides enhanced durability while requiring minimal maintenance.



Applications

The FG2-11 Vertical Inline High Pressure Pump is suitable for:

• 500–750 LPH RO Plants

• Reverse Osmosis Systems

• Water Purification Systems

• Pressure Boosting Systems

• Industrial Water Circulation

• Small Water Treatment Plants

• Commercial Filtration Systems

Salient Features

• Compact Vertical Inline Design

• High Pressure Output for RO Systems

• Energy Efficient Operation

• Corrosion Resistant Pump Components

• Low Noise and Vibration

• Heavy Duty Mechanical Seal

• Reliable Continuous Duty Performance

• Easy Installation and Maintenance

Technical Specifications

Specification	Details
Model Number	FG2-11 (BSBD)
Pump Type	Vertical Inline High Pressure Pump
Flow Rate	0 – 87.7 L/min
Maximum Head (Flow Height)	102.8 m
Voltage	238 – 240 V
Frequency	50 Hz
Power Factor (PF)	0.93
Material	Stainless Steel

Material of Construction

Pump Component	Material
Pump Casing	Cast Iron
Impeller	Stainless Steel 304
Diffuser	Stainless Steel 304
Pump Shaft	Stainless Steel 304
Mechanical Seal	Silicon Carbide / Carbon / Viton
Motor Frame	Aluminum (PDC)
Cooling Fan	Engineering Plastic



Why Choose Flowguards Pumps

Flowguards manufactures high-quality Vertical Inline High Pressure Pumps and pump spare parts designed for RO plants and industrial water treatment systems.

Our pumps are built using durable materials and advanced manufacturing techniques to ensure high efficiency, reliable pressure output, and long operational life. The FG2-11 (BSBD) model is an ideal solution for compact RO systems requiring stable pressure and efficient performance.
